It uses a high-quality imported fiber laser which results in high precision cutting with minimum material loss.
The workpiece will not be deformed and requires minimum polishing.
Greatly reduces the production time and cost compares to the traditional method of jewellery making.
It has functions to do rotary cutting like cutting bangles and rings, and auto-feed conveyor cutting for mass production.
This machine comes complete with pre-installed easy to use software that is compatible with many vector file formats.
It is also suitable for other industry which requires high-speed precision cutting.
Please contact us for more details.
1. High quality Imported fiber laser and cutting head
2. Stable laser output.
3. Customized software. Automatically optimized the cutting paths to minimize the cutting time.
4. Uses high-quality servo motor for high accuracy cutting.
5. Auto-tracking focusing. When cutting the uneven workpiece, the system is able to track and auto-focus the laser for accurate and even cutting.
6. Auto-feed cutting for roll material.
7. Rotary cutting for bangles.
8. Highly efficient material lost retrieval system design.
Laser Source :
Imported Fiber Laser
Laser Wavelength :
Cutting Area :
300mm × 300mm
Cutting Thickness :
Maximum 5.0mm (Depending on material)
Cutting Line Width :
0.04 ~0.12mm(Depending on material)
Cutting Speed :
300mm ~ 2000mm/min
Cutting Accuracy :
Cooling Mode :
Cutting Air Pressure Requirement :
6 ~ 16 bar (Depending on material)
Maximum Power Consumption :
3kW / 5kW
Power Supply :
220V / 1P
Machine Dimension :
980mm × 960mm × 1730mm
320Kg (Net) / 400Kg (Gross)
*Our products undergo continuous improvements. This information is based on current
knowledge. We reserve the right to make changes without prior notice.
