Dot Peen Marking Machine
Touch Screen Dot Pin Marking Machine
           Rings/ Bangles Engraver
Specification
  • Model
    CPM-R8
  • Marking Character Size
    0.5-15mm (Alphabets);
    0.7-15mm (Chinese Characters)
  • Outside Mark Diameter
    15-80mm
  • Inside Mark Diameter
    15-60mm
  • Ring Width
    ≤20mm
  • Flat Marking Area
    20mm × 35mm
  • Flat Marking Character Size
    Maximum 20mm
  • Computer
    Included
  • Marking Software
    Cosmark (Developed by Cosmo);
    Compatible with WINDOWS XP/ VISTA/ 7/ 8/ 10
  • Fonts Supported
    All WINDOWS Compatible Fonts
  • Languages Supported
    Multi-Language
  • Picture Format Supported
    Monochrome Bitmap (BMP)
  • Max Power Consumption
    180W
  • Power supply
    220V/1P(Standard);
    110V/1P(Optional)
  • Machine Dimension
    470mm×230mm×380mm (L×W×H)
  • Weight
    15kg(Net)/ 18kg(Gross)

For engraving an inner wedding ring, the dot pin marking machine typically uses a specialized attachment or fixture designed specifically for holding and positioning the ring securely. The ring is placed in the fixture, and the machine is programmed with the desired text or design to be engraved.

The dot pin marking process allows for precise and permanent marking on the inner side of the ring without causing significant damage or deformation. It can be used to engrave names, dates, personalized messages, or even intricate patterns onto the inner surface of the ring.

This method of engraving is commonly used in jewelry manufacturing and customization to add a personal touch to wedding rings and other jewelry items. The resulting engravings are durable, legible, and long-lasting, making them ideal for sentimental and commemorative purposes.

Machine Size


Samples Display
