Computerized Pin Marking Machine Display Dot Peen Marking Machine

Dot peen marking machine is a type of industrial equipment used to permanently mark or engrave text, logos, serial numbers, and other information onto various materials such as metal, plastic, and wood. It uses a pneumatically or electrically driven pin to create small dots on the surface of the material, which combine to form the desired marking. Dot peen marking machines are commonly used in manufacturing and assembly operations for product identification and traceability purposes, and can be programmed to automate the marking process for increased efficiency and accuracy.

SEND INQUIRY NOW

Computerized Pin Marking Machine

Rings/ Bangles Engraver

Specification

Model
CPM-R8
Marking Character Size
0.5-15mm (Alphabets);
0.7-15mm (Chinese Characters)
Outside Mark Diameter
15-80mm
Inside Mark Diameter
15-60mm
Ring Width
≤20mm
Flat Marking Area
20mm × 35mm
Flat Marking Character Size
Maximum 20mm
Computer
Included
Marking Software
Cosmark (Developed by Cosmo);
Compatible with WINDOWS XP/ VISTA/ 7/ 8/ 10
Fonts Supported
All WINDOWS Compatible Fonts
Languages Supported
Multi-Language
Picture Format Supported
Monochrome Bitmap (BMP)
Max Power Consumption
180W
Power supply
220V/1P(Standard);
110V/1P(Optional)
Machine Dimension
470mm×230mm×380mm (L×W×H)
Weight
15kg(Net)/ 18kg(Gross)

The CPM-R8 pin marking machine has a touchscreen WINDOWS OS computer built in. It is an all-in-one machine that plugs and plays. It can be used with a wired or wireless mouse and keyboard.

It has the same functions as the CPM-R

√ mark the inside and outside of rings

√ mark the inside and outside of bangles

√ mark on flat surfaces

It produces a shiny marking with no material loss and no additional polishing required.

Machine Size
